The Holes Design for the High-density PCB Manufacturing

We know that in PCB design, seemingly simple hole often bring great negative effects to circuit board design. Therefore, in the design, we should try our best to do the following:

1. Considering both cost and signal quality, choose a reasonable holes size. For example, for the 6-10 layer memory module PCB design, the aperture of 10/20Mil (drilled hole/pad) is better. For some high-density small-sized boards, you can also try to use the hole of 8/18Mil. Under current technical conditions, it is difficult to use smaller hole. For the holes of the power supply or ground wire, a larger size can be considered to reduce the impedance.

2. The use of a thinner custom led circuit board is conducive to reducing the two parasitic parameters of the holes.

3. Try not to change the layers of the signal traces on the pcb production, that is to say, try not to use unnecessary holes.
